TiLOW : Line Array.

Ultra Compact 12" Bass Extension for TiRAY

TiLOW Photo
TiLOW Photo
TiLOW Photo
TiLOW Photo
TiLOW Photo
TiLOW Photo
TiLOW Size Comparison
TiLOW Photo
TiLOW Photo
TiLOW Photo
TiLOW Photo
TiLOW Photo
TiLOW Photo
TiLOW Size Comparison

Ultra compact 12” bass extension, Extended frequency range 44 - 300 Hz (-6 dB)

  • The TiLOW is NOT a subwoofer, it is a bass extension system operating in the range 44 - 300 Hz which overlaps both the low range of TiRAY and the subwoofers providing more essential energy and control in the lower range of the system.


Main Features

  • Ultra compact 12” bass extension
  • Extended frequency range: 44 – 300 Hz (-6 dB)
  • Power handling: 1000 W (AES)
  • Rigging is compatible with TiRAY
  • Flyable or ground stackable
  • System integration with LINUS Loudspeaker Management Amplifiers

This post is also available in: Deutsch (German)

Overview

TiLOW is the super-compact bass extension for the TiRAY line array, which increases long throw capability of the TiRAY system, and enhances its LF headroom. First and foremost, TiLOW isn’t a sub: it does, however, operate between 44 Hz and 300 Hz, which overlaps both the low end of TiRAY and CODA’s subwoofers, providing more energy and control in the lower range of the system thanks to its dual 12″ drivers and compact, vented exclosure, which provides a signature low-end punch to your sound.

TiLOW is very compact and versatile: fly it on top of a TiRAY array at a show to increase the long throw capacity of the system; fly it beside TiRAY to optimise horizontal directivity; set it in a TiRAY array between the cabinets to help avoid balcony reflections in a theatre; or groundstack it with TiRAY as a compact and powerful solution for smaller venues.

System Solution

The TiLOW is designed to work exclusively with dedicated CODA Audio LINUS5-C or LINUS10-C amplifiers as an integrated solution for DSP, amplification, network remote control and diagnostic.
The integrated solution ensures optimal performance and protection.

Applications

  • TiLOW flown on the top of TiRAY array (44 – 300 Hz) – increases the array length and enlarges the system long throw capability
  • TiLOW flown beside the TiRAY array (44 – 150 Hz) – optimises the system horizontal directivity
  • TiLOW in array between TiRAY cabinets (44 – 300 Hz) – avoids balcony reflections
  • TiLOW ground-stack with TiRAY (44 – 300 Hz) – compact and powerful solution for smaller venues
  • Primarily designed for integration into the TiRAY line arrays, the TiLOW is also suited for a variety of applications in touring and installations where ultra compact size, high precision, deep bass with directivity control is needed.

Application Advantages

  • Increases the long throw capability of TiRAY
  • Enhances the systems low frequency headroom
  • Overlaps both the low range of TiRAY and the ground subwoofers reducing the need for additional subs
  • Provides 12” sonic signature

Options

Standard RAL colours and weather protection options are available on request. The integrated rigging system allows quick and easy flying or ground stacking.

Specification




Type: Ultra Compact 12″ Bass Extension for TiRAY
Application: Bass extension for TiRAY
Frequency response: 44 – 300 Hz (-6 dB)
Power handling (AES / peak): 1000 W / 4000 W
Sensitivity 1 W / 1 m:* 95 dB
Maximum output peak:** 135 dB
Amplification, cabinets per amplifier:
LINUS5-C Optimum / Maximum: 8/12
LINUS10-C Optimum / Maximum: 8/12
LINUS12C Optimum / Maximum: 8/16
LINUS14D Optimum / Maximum: 8/16
Components: 12″ ultra low distortion woofer, 4″ (101.6 mm) VC, 1000 W (AES)
Nominal impedance: 8 Ohm (1+/1-)
Input connectors: 2x Neutrik™ NL4MP
Suspension: Flying hardware integrated, M20
Enclosure material: Birch plywood
Finish: Polyurea black coating
IP rating (IEC 60529): IP54
Weather protection options: Standard IP55: IP55 (Amphenol connectors)
MG1 (Marine Grade 1): IP55
Dimensions: 404 x 344 x 490 mm / 15.91 x 13.54 x 19.29″
Net weight: 20 kg / 44.09 lbs

* Half space loading.
** Measured with pink noice 6 dB crest factor.

Accessories

  • FR-TR

    This post is also available in: Deutsch (German)

    Frame for flying or ground stacking TiRAY and TiLOW

  • EXBAR-TR

    This post is also available in: Deutsch (German)

    Extension bar for FR-TR and FRT-TR

  • TGA

    This post is also available in: Deutsch (German)

    Groundstacking and flying adaptor for TiRAY

  • SA-TR

    This post is also available in: Deutsch (German)

    Splay adapter for TiRAY.
    Enables connection of TiRAY frames below TiRAY Systems

  • LP-AR

    This post is also available in: Deutsch (German)

    Laser plate for FR-AR and FR-TR frame

  • CO-TiLOW

    This post is also available in: Deutsch (German)

    Protection cover for 1x TiLOW or 1x U12-SUB

  • CO-TiLOW EX

    This post is also available in: Deutsch (German)

    Protection cover extension for 1x TiLOW

Downloads

FileAction
TiLOW DatasheetDownload
GLL file for EASE and EASE Focus 3 Download
Loading Capacity Calculation (TiRAY, TiLOW)Download
TiLOW CAD Drawing 2DDownload
TiLOW CAD Drawing 3DDownload
TiLOW Accessories - DrawingsDownload
